pneumatic control valve, linear type, body A351 CF8+PTFE, trim 304+PTFE, DN25, PN16, seat RPTFE, double flanged, FC , with positioner 4-20mA.

Product Show

We are delivering the order of pneumatic control valve, linear type, body A351 CF8+PTFE, trim 304+PTFE, DN25, PN16, seat RPTFE, double flanged, FC , with positioner 4-20mA.

Product Description

Product name	Pneumatic control valve
Type	Single seated
End	Double flanged
Working temp	-20 ℃ to 150 ℃
Working pressure	0.9 Mpa
Body material	CF8+PTFE
Disc material	304+PTFE
Seat material	RPTFE
Pressure rating	PN16
Size	DN25
Flange standard	EN 1092-1
Face to Face Standard	GB/T 12221
Test standard	GB/T 13927
Application	alkali
Operation	Diaphragm type pneumatic actuator
Project location	Chile
